Power 430XL


  • Automatic chrome-plated double-column sawing machine with long index stroke for material feeding in single stroke up to 3000 mm

The highest productivity levels, even on the most demanding materials

Perfect blade guide control and excellent positioning accuracy.
That’s all you need to get the best cuts and the ISTech Power sawing machines can guarantee them thanks to:

  • maximum control of the cutting feed, that can be adjusted independently, from the sawing machine, at any time
  • 0.01mm positioning accuracy thanks to the special drive system installed on the carriage, that allows obtaining finished pieces of exactly the same size

Less waste
Precise cuts every time; a certainty that allows you to reduce machining allowances and material waste (besides the subsequent processing times). A goal reached also thanks to the possibility to avoid trimming cuts and also to the split front vice that limits bar remainders to the maximum.

Power XL takes care of it all
All the adjustments are made automatically by the machine; just indicate the type of material and its dimensions and the sawing machine will set all the other parameters and adjust them continuously during the work cycle in such a way as to obtain the best possible results.
The discharge outlet of the chips conveyor is installed at a height of 1 m, to allow for many hours of operation without the intervention of the operator.

Industry 4.0
With the 4.0 package, the Power XL sawing machines are able to communicate with your management program, allowing you to load cutting programs and make adjustments remotely, monitor the operation of the sawing machine from your smartphone, receive remote technical support and much more.

Cutting capacity

Cutting capacity90°
430x430

Technical data

Material feed lenght, single stroke1000 – 2000 – 3000 mm
Blade dimension5450 x 41 x 1.3 mm
Blade speed, infinitely variable15 -120 m/1′
Cutting feed speed, infinitely variable5-100 mm/1′
Band drive motor, inverter controlled5.5 Kw
Total connected load13 kw
Material feed lenght, multiple feed99.999 mm
Index positioning accuracy± 0.01 mm
Index speed250 mm/sec
Minimum sawing diameter25 mm
Material pass line800 mm
Overall dimension2520 x4000/5000 x 2500h mm
Weight (approx)4300/4800 Kg
